Item | Paramter |
Board Type: | Rigid PCB, Flexible PCB, metal core PCB,Rigid-Flex PCB |
Board Shape: | Rectangular, Circular and any Odd Shapes |
Size: | 50*50mm~400mm * 1200mm |
Min Package: | 01005 (0.4mm*0.2mm),0201 |
Fine Pitch Parts: | 0.25mm |
BGA Package: | Dia. 0.14mm, BGA 0.2mm pitch |
Mounting Accuracy: | ±0.035mm(±0.025mm) Cpk≥1.0 (3σ) |
SMT Capacity: | 3 Million~4 Million Soldering Pad/day |
DIP Capacity: | 100 Thousand Pins/day |
Assembly Capacity | 100 Thousand Pins/day |
Parts Sourcing: | All components sourced by Cmy, Partial sourcing, Kitted/Consigned |
Parts Package: | Reels, Cut Tape, Tube & Tray, Loose Parts and Bulk |
Testing: | Visual inspection; AOI ; X-RAY ; Functional Testing,ICT |
Types of Solder: | lead-free (RoHS Compliant) assembly services |
Assembly Option: | From SMT to Assy,conformal coating ,Press fit |
Stencils: | Laser cut stainless steel stencils，Nano stencil ,FG stencil |
File Formats: | Bill of Materials，PCB(Gerber Files)，Pick-N-Place File (XYRS) |
Quality Grade: | IPC-A-610,IPC-A-600 |
